Brasch GENERATION 2 – REMOTE TRANSMITTERS (CO and NO2)

Brasch TRNS Generation 2 with a Carbon Monoxide and a Nitrogen Dioxide Sensor

The below is a Generic Description of the Sensor

Click here for more information from Brasch

The Brasch Generation 2 remote transmitters are designed to monitor toxic or combustible gases and provide an output signal to conveniently add gas detection capabilities to any new or existing system. Transmitters are available for carbon monoxide (CO), nitrogen dioxide (NO2), methane (CH4), propane (C3H8), hydrogen (H2), and oxygen (O2). A digital output is provided via Modbus RTU while an analog output is provided via a user selectable 4-20 mA, 0.2-1 VDC, 1-5 VDC, or 2-10 VDC signal. Remote transmitters can be used in conjunction with Brasch GSE Generation 2 Standalone Detectors, GDCP-Touch Multi-Zone Control Panels, and most BMS/DDCS/VFDs.

Fixed industrial gas transmitter for monitoring carbon monoxide (CO) and nitrogen dioxide (NO2) and controlling HVAC equipment. For use in gasoline and diesel exhaust monitoring applications. Can be connected with GSE Generation 2, GDCP-Touch, or a BMS/DDCS. Covers up to 9,000 sq. ft.
